Firestorm + Icestorm · Apple
This is the historic moment ! Apple's 1st desktop CPU ! The M1 !
Built on the same Apple A14 Performance-cores (Firestorm), it took the world by storm !
It beats the competition both on single-thread performance as well as
performance per watt. Two very important metrics.
Energy-efficient cores (E-cores) are based on "Icestorm" microarchitecture.
First time in the world one can build a very thin laptop,
that works 15 hours on a battery,
and delivers amazing Core i7-like performance levels and is completely silent !
Such a combination has NEVER existed before and was considered impossible until now !
Welcome to the ZERO noise computing ! Macbook Air M1, 2020 !
Probably the most unique and most amazing laptop ever built.
(despite it's lack of I/O, but that is a story for another day...)
Later variants include The M1 Pro, M1 Max and M1 Ultra as it's big brothers.
A14 - 6 cores (2P+4e); 4 GPU cores; mem.bandwidth = 34.1 GB/sec; 11.8 billion transistors.
M1 - 8 cores (4P+4e); 7-8 GPU cores; mem.bandwidth = 68.3 GB/sec; 16 billion transistors.
M1 Pro - 10 cores (8P+2e); 14-16 GPU cores; mem.bandwidth = 204.8 GB/sec; 33.7 billion transistors.
M1 Max - 10 cores (8P+2e); 24-32 GPU cores; mem.bandwidth = 409.6 GB/sec; 57 billion transistors.
M1 Ultra - 20 cores (16P+4e); 48-64 GPU cores; mem.bandwidth = 819.2 GB/sec; 114 billion transistors.
4 result(s) recorded for this family.
Flagship: Apple M1 / Mac Mini
ST score/GHz: 1,437 · MT score/Watt: 1,178
| Specification | Value |
|---|---|
| Introduced | 2020 |
| Arch Generation | 14 |
| Architecture / Codename | Firestorm + Icestorm |
| Cores / Threads | 4P+4e (4 Performance Cores + 4 efficiency cores) |
| Technology Node | 5 nm (TSMC N5) |
| Die Size | 119 mm^2 |
| Transistors | 16 billion |
| Frequency | 3200 MHz |
| Instructions | 192 KB + 128 KB /P-core |
| TDP | ~15 Watts |
| Cache L2 | 12 MB /P-cluster |
| Memory Type | LPDDR4X |
| Memory Bandwidth | 68.3 GB/s; (up to 819.2 GB/s for M1 Ultra) |
| Memory Size Max | 16 GB (up to 128 GB for M1 Ultra) |
